Leveraging the Lightstep API to visualize the reporting status of your services in Grafana

Lightstep recently added several new APIsnew APIs to help developers access the high value data being sent to Lightstep from their systems and integrate the rich analysis built on that data into their existing workflows. This allows customers to extend the value that Lightstep provides out-of-the-box and enable new ways to innovate. In this post, you’ll learn how to extend Lightstep in your organization to analyze discrepancies in span volume over time.

Lightstep customers send trillions of spans from their applications to MicrosatellitesMicrosatellites hosted and managed in their own environments. Data going to the Satellites is not sampled at the clients. Hence, depending on available resources (Satellite instances) and throughput of data, sometimes some spans get dropped, either at the client (throughput too high) or at the Microsatellites (not enough Microsatellites). While there are controls available for monitoringmonitoring and for resolvingresolving issues with dropped spans, when it happens, the first question that is usually asked is "Which service was the problematic one?".

Lightstep offers a Reporting StatusReporting Status view for all services currently reporting data to the Lightstep Microsatellites. This view pulls metrics from the Microsatellites directly, and only displays the "last" metric at a point in time. While this is useful for just-in-time debugging, it does not have enough data for analyzing historical discrepancies and span data volume. This is where the newly released Reporting Status APIReporting Status API can help by providing a way to analyze the historical reporting status of your services.

Lightstep API Overview with Grafana

In this tutorial, we will setup the following simple workflow:

1. Call the Lightstep Reporting Status API - Since this is just a simple HTTP call, the possibilities on how you want to do this are endless. I chose Node-REDNode-RED because it has a simple, flexible, low-code graphical interface for creating a workflow that can be scheduled. Node-RED is built for event driven applications, but it will also work for this scheduled cron job case.

NOTE: Here is an exampleHere is an example of a simple Node.js script that achieves the same purpose as Node-RED, if that is your preference.

2. Store the returned results in a time series database - Any time series database should work as long as you have a way to write data to it in Step 1 and read data from it in Step 3. I chose InfluxDBInfluxDB.

3. Visualize the data - For this tutorial, we’ll use Grafana to read the data from our DB. In my opinion, GrafanaGrafana is quite possibly the best open source graph visualization solution.

Using the Lightstep API

  • You will need a Lightstep account and a Lightstep API key. Get it hereGet it here.

  • Docker and docker-compose installed on your machine.

Setup -- Docker, Node-RED, InfluxDB, and Grafana

We will use Docker to set up a container each for Node-RED, InfluxDB, and Grafana, map the appropriate default ports, and connect them all as part of one docker network for easier communication.

# docker-compose.yml

version: "3"
	image: nodered/node-red:latest-12
	container_name: nodered
  	- 1880:1880
  	- lightstep
	image: influxdb:1.8-alpine
	container_name: influxdb
  	- 8086:8086
  	- INFLUXDB_DB=lightstep
  	- INFLUXDB_USER=lightstep
  	- lightstep
	image: grafana/grafana:7.3.0
	container_name: grafana
  	- 3000:3000
  	- lightstep
$ docker-compose up -d

Node-RED workflow

This is the workflow we will be building in Node-RED:

node red final workflow

Before we start developing our workflow, we need to install two nodes that are not included out of the box. node-red-contrib-cron-plusnode-red-contrib-cron-plus for scheduling our flow, and node-red-contrib-influxdbnode-red-contrib-influxdb for writing data to InfluxDB.

# SSH into the container
$ docker exec -it nodered bash

# Install the packages
bash-5.0$ npm install --save node-red-contrib-cron-plus node-red-contrib-influxdb

# Exit the container
bash-5.0$ exit

# Restart the nodered container for the new nodes to register
$ docker-compose restart nodered

Now, visit localhost:1880 in your browser to access the Node-RED GUI. You should have the newly installed cronplus and influxdb nodes in the left drawer. Let's start building our workflow.

1. Schedule Trigger - Drag the cron-plus node to the board and double click to configure it. We want our flow to trigger every minute, which maps to a cron schedule of 0 * * * * * *. This should already be selected as default. Feel free to change any metadata you want or other options for the node.

2. Get Reporting Status - When triggered, we want our flow to make an HTTP call to Lightstep APILightstep API. We will use the http request node for this. Drag the node to the board and double click to configure the settings. Set Method to GET and URL to, substituting your organization and project names. Check the Use Authentication box, set the type to bearer authentication and paste in your API key into the subsequent box. Finally, click the Return dropdown and choose a parsed JSON object. Give it a name if you'd like to. This is what our node should look like:


3. Cleanup Data - The response from the Lightstep API includes a JSON object, and the result is a nested array of values for each service. We will add a function node to just get the array,

msg.payload =;
return msg;

a split node to split the array into individual messages,


and a change node to drop some fields that are not needed.


4. Map tags - Before we send the data to InfluxDB, we map some fields that we would like to group by in Grafana later. The influxdb-outinfluxdb-out node interprets two objects inside an array of a message that is sent to the node as values and tags. So we use a function node to convert our simple message object back into an array so that it is written to the DB appropriately.

var tmp = msg.payload;
msg.payload = [
	spans_count: tmp.spans_count,
	client_dropped_spans_count: tmp.dropped_spans_count,
	satellite_dropped_spans_count: tmp.collector_dropped_spans_count,
	updated_micros: tmp.updated_micros,
	service: tmp.component_name,
	platform: tmp.platform,
return msg;

5. Write to InfluxDB - Finally, drag an InfluxDB node to the board and double click the node to setup a database first, with the values pointing to our InfluxDB container. Then, set a name for the Measurement field to be able to distinguish data in InfluxDB if you choose to use it for other purposes later. I set this as "rs" for reporting status.


Tip: We can use the name influxdb as host, because all our containers are part of the same network. So the container name resolves to the IP address. Otherwise you can also docker inspect influxdb to get the IP address of the container and set that as host.

6. Connect the Flow - Draw the connections between the nodes and Deploy the flow from the top right. If everything is set up correctly, the flow should start pushing data to InfluxDB every minute. You can click the bug icon in the right sidebar to debug the flow, any errors would show up there.

This entire flow is set up in the UI, but you can also load it by importing the flow.jsonflow.json file into Node-RED.

Visualize Lightstep data in Grafana

Once the data is in InfluxDB we can visualize it in Grafana. Visit localhost:3000 in your browser. If this is your first login, Grafana will ask for a username and password. admin is the default for both.

1. Set up InfluxDB datasource

InfluxDBInfluxDB is included as a bundled datasource in Grafana. You can configure it to point to our own local InfluxDB instance.


2. Create a Reporting Status Timeseries panel

Graphing our timeseries data in Grafana is pretty straightforward. Create a new Panel and choose our InfluxDB datasource to select span_count (or client_dropped_span_count or satellite_dropped_span_count) and group by tag(service) to graph the timeseries. Since we are gathering this data every minute, I also set the resolution of the panel to 1m.


You can now integrate this panel into other existing dashboards for your environments or services, including existing Lightstep Satellite dashboards to have higher fidelity visualizations about the reporting status of your services.


This tutorial covered creating a historical time series to help analyze discrepancies in span volume, which if left unresolved can create expensive blind spots in your observability efforts. By combining the rich data of the Lightstep Reporting Status API and Grafana’s visualization tools, you can quickly get the insights needed to make informed decisions about the health and performance of your environments.
