Getting Started with OpenTelemetry Alphas: Golang

For up-to-date information on running OpenTelemetry in production, please visit our Getting Started Guide for OpenTelemetry and GolangGetting Started Guide for OpenTelemetry and Golang

We're excited that OpenTelemetry is moving to the alpha phase. It's a great time to get involvedto get involved and share your feedback.

You can check out the full [SIG progressSIG progress] here.

Alpha v0.1

The following examples use the Alpha v0.1 version of OpenTelemetry-GoOpenTelemetry-Go (an OpenTelemetry comptible tracer). These examples assume that the Jaeger all-in-one imageJaeger all-in-one image is running locally via Docker:

$ docker run -d -p 6831:6831/udp -p 16686:16686 jaegertracing/all-in-one:latest`

Setting up your tracer

There are three objects configured here: a new tracing SDK, a new simple span processor, and a new Jaeger exporter.

import (
    "context"
    "log"

    "go.opentelemetry.io/api/trace"
    "go.opentelemetry.io/exporter/trace/jaeger"
    sdk "go.opentelemetry.io/sdk/trace"
)

func setupTracer() (trace.Tracer, *jaeger.Exporter, error) {
    // Register installs a new global tracer instance.
    tracer := sdk.Register()

    // Construct and register an export pipeline using the Jaeger
    // exporter and a span processor.
    exporter, err := jaeger.NewExporter(
        jaeger.Options{
            AgentEndpoint: "localhost:6831",
        },
    )
    if err != nil {
        return nil, nil, err
    }

    // A simple span processor calls through to the exporter
    // without buffering.
    ssp := sdk.NewSimpleSpanProcessor(exporter)
    sdk.RegisterSpanProcessor(ssp)

    // Use sdk.AlwaysSample sampler to send all spans.
    sdk.ApplyConfig(
        sdk.Config{
            DefaultSampler: sdk.AlwaysSample(),
        },
    )

    return tracer, exporter, nil
}

The returned Tracer is ready to use. The returned Exporter will be useful for flushing spans before exiting the process.

Start and end a span

import "go.opentelemetry.io/api/trace"

func sayHello() {
    ctx := context.Background()
    tracer := trace.GlobalTracer()

    ctx, trace := tracer.Start(ctx, "say-hello")

    trace.End()
}

There is another way to start a span that supports recovering from panics automatically, so that spans still send in these situations.

import "go.opentelemetry.io/api/trace"

func sayHello2() {
    ctx := context.Background()
    tracer := trace.GlobalTracer()

    err := tracer.WithSpan(ctx, "say-hello", func(ctx context.Context) error {
        // This body is traced, and the span will End() despite panics.
        return nil
    })

    if err != nil {
        // ...
    }
}

Creating child spans

This example main() function sets up the tracer and sends three spans, two of them children, as part of a single trace. Note the call to exporter.Flush() to send spans before exiting the process.

func main() {
    // Setup tracing and get a Tracer instance.  We'll use the
    // exporter to flush before exiting.
    tracer, exporter, err := setupTracer()

    if err != nil {
        log.Fatal("Could not initialize tracing: ", err)
    }

    // Tracing uses the standard context for propagation, we'll
    // start with a background context.
    ctx := context.Background()

    _ = tracer.WithSpan(ctx, "foo",
        func(ctx context.Context) error {
            tracer.WithSpan(ctx, "bar",
                func(ctx context.Context) error {
                    tracer.WithSpan(ctx, "baz",
                        func(ctx context.Context) error {
                            return nil
                        },
                    )
                    return nil
                },
            )
            return nil
        },
    )

    // The Jaeger exporter will have buffered spans at this point, send them.
    exporter.Flush()
}

Trace an HTTP request

This example shows how to propagate trace context across an HTTP request. First we have to select the type of context carrier—in this example we use W3C. On the client side, a call to httptrace.W3C configures the http.Request object to use W3C trace context headers, and a call to httptrace.Inject both injects the headers and applies conventional HTTP attributes to the span.

import (
    "context"
    "io/ioutil"
    "net/http"

    "go.opentelemetry.io/api/trace"
    "go.opentelemetry.io/plugin/httptrace"
    "google.golang.org/grpc/codes"
)

func sayHTTPHello(ctx context.Context) {
    var body []byte
    client := http.DefaultClient
    tracer := trace.GlobalTracer()

    tracer.WithSpan(ctx, "client-call",
        func(ctx context.Context) error {
            req, _ := http.NewRequest("GET", "http://localhost:7777/hello", nil)

            ctx, req = httptrace.W3C(ctx, req)
            httptrace.Inject(ctx, req)

            res, err := client.Do(req)
            if err != nil {
                panic(err)
            }
            body, err = ioutil.ReadAll(res.Body)
            res.Body.Close()
            trace.CurrentSpan(ctx).SetStatus(codes.OK)

            return err
        })
}

Continuing on the server side, this is an HTTP handler that adds tracing support.

func helloHandler(w http.ResponseWriter, req *http.Request) {
    tracer := trace.GlobalTracer()

    // Extracts the conventional HTTP span attributes,
    // distributed context tags, and a span context for
    // tracing this request.
    attrs, tags, spanCtx := httptrace.Extract(req.Context(), req)

    // Apply the distributed context tags to the request
    // context.
    req = req.WithContext(tag.WithMap(req.Context(), tag.NewMap(tag.MapUpdate{
        MultiKV: tags,
    })))

    // Start the server-side span, passing the remote
    // child span context explicitly.
    _, span := tracer.Start(
        req.Context(),
        "hello",
        trace.WithAttributes(attrs...),
        trace.ChildOf(spanCtx),
    )
    defer span.End()

    _, _ = io.WriteString(w, "Hello, world!\n")
}

View your traces

If you have Jaeger all-in-one running, you can view your traces at localhost:16686.
